Description
Specifications
| Specifications | CNC 65 B1 / CNC 65 B2 | |
|---|---|---|
| HORSE POWER | 26HP | |
| MAX. BENDING CAPACITY(mm) | 65×3 | |
| MAX. BENDING RADIUS(mm) | 220 | |
| MAX. BENDING ANGLE(°) | 190 | |
| MAX. FEEDING POSITIONING LENGTH(mm) | 2500 | |
| MAX. FEEDING LENGTH WITH MANDREL(mm) | 3900 | |
| BENDING ACCURACY(°) | ±0.1 | |
| BENDING SPEED(°/sec) | 35 | |
| FEEDING ACCURACY(mm) | RACK | ±0.1 |
| BALLSCREW | – | |
| FEEDING SPEED(mm/sec) | 1~800 | |
| TURNING ACCURACY(°) | ±0.1 | |
| NUMBER OF PROGRAMS | 200 | |
| BENDING NO./PROGRAM | 30 EDIT LINES / PROGRAM | |
| TURNING SPEED(°/sec) | 150 | |
| RADIUS DIFFERENCE BETWEEN STACKS(mm) | 80 | |
| DIMENSIONS(cm) | 525x135x135 | |
| WEIGHT (kg) | 4400 | |
Features
LCD TOUCH SCREEN：
- 8.4” color touch screen with multiple languages for option.
- PLC based with WIN CE / NET friendly use programming.
PARAMETER LIST & 3D SIMULATION：
- Able to set up mandrel pre-backward, booster, mandrel lubrication and auto bending reverse. It can save 99 sets program.
Error Message：
- Error description and flashing alarm on abnormal operational section offer instant trouble shooting.
Applications
BENDING DIES
CNC BR1/2 Single/Dual stacks for bending.
| MODEL | CNC BENDING |
|---|---|
| BENDING DIE |  A1  A2  A3 |
| CLAMPING DIE |  B1  B2  B3 |
| PRESSURE DIE |  C2 |
| SINGLE / MULTI- BALL MANDREL |
 D1  D2  D3 |
| CLAMP CHUCK |  E1 |
| WIPER DIE |  F1 |
Additional information
| Business Type | Manufacturer |
|---|---|
| Delivery | Shipment within 30 days since the date of payment |
| Minimum Quantity | 5 |
| Place Of Origin | Taiwan |
